TPFZ Series Pallet Turner / Pallet Changer / Pallet Replacement Equipment for Pharmaceutical Industry

Attribute

5. Product Introduction

TPFZ "tray flipping machine tray replacement machine pharmaceutical industry tray replacement equipment standard configuration:

1、 A set of steel protective nets around the machine at a height of 2 meters;

2、 A set of 1.2-meter extended protective net at the front end of a 2-meter high machine;

3、 One set of infrared safety protection device;

4、 Machine color: blue;

5、 Protective fence color: yellow

TPFZ "tray flipping machine tray replacement machine pharmaceutical industry tray replacement equipment working steps:

1、 For goods that cannot be placed upside down after replacing the pallet:

1. Use a forklift to place the goods onto the pallet changing machine;

2. Pinch the goods;

3. Flip the pallet and goods together 180 degrees;

4. Release the clamp;

5. Replace the tray;

6. Re clamp the goods;

7. Flip the pallet and goods together again by 180 degrees;

8. Release the clamp;

9. Remove the goods along with the pallet from the pallet changing machine using a forklift.

2、 For goods that can be placed upside down after replacing the pallet:

1. Use a forklift to place the goods onto the pallet changing machine;

2. Place the tray that needs to be replaced on top of the goods;

3. Pinch the goods;

4. Flip the pallet and goods together 180 degrees;;

5. Release the clamp;

6. Remove the original pallet from the top of the goods;

7. Remove the goods along with the pallet from the pallet changing machine using a forklift.

Shanghai Baoduan Machinery Manufacturing Co., Ltd. is located in Baoshan District, Shanghai, an international metropolis. It is a professional mechanical production enterprise engaged in equipment manufacturing and equipment R&D.

The company focuses on production equipment for metallurgical processing, as well as winding and packaging machine equipment for metal strips, pipes, profiles, tires, etc. Meanwhile, to solve problems such as product packaging and transfer in the actual production of metal strip processing enterprises, our company has also developed winding and packaging equipment for materials like metal strips, metal plates, pipes, and wires—including steel strip Winding Machines, copper coil winding and packaging machines, steel wire winding machines, steel pipe winding machines, horizontal winding machines, etc.—as well as industrial turning equipment such as 90-degree Steel Coil tilters, aluminum Coil tilters, Mold tilters, and 180-degree tilters.
